Figure: Four-Port 10-GbE Fiber SFP+ Card (NIC-1-010G-4SFPP)
Port | Description |
P0, P1, P2, P3 | Provides access to 10/100/1000 Base-TX |
LED | Description |
Speed | Blue = 10 G Yellow = 1 G |
Link/Activity | Link = Green Activity = Blinking |
Specification | Definition |
Connectors | Four small form factor pluggable (SFP+) Cage |
NICs | Manufacturing Part # | Orderable Part # |
SFP 1-GbE LX | 410-00140-01 | TRC-1-SFP-LX |
SFP+ 10-GbE SR | 410-00143-01 | TRC-1-SFPP-SR |
SFP+ 10-GbE LR | 410-00144-01 | TRC-1-SFPP-LR |
