Figure: Four-Port 1-GbE Copper Base-T (NIC-1-001G-4TX)
Port | Description |
P0, P1, P2, P3 | Provides access to 10/100/1000 Base-TX |
LED | Description |
Link/Activity (LED1) | Link: Green |
Activity: Blinking green | |
Speed (LED2) | 1 G: Yellow |
100 M: Green | |
10 M: Off |
Connectors | Four shielded RJ-45 |
Cables and operating distance | 10 Base-T Category 3, 4, or 5 maximum 100 m 100 Base-Tx Category 5 maximum 100 m 1000 Base-T Category 5E maximum 100 m |
